SIEMENS SITRANS LR560 Radar Level Transmitter
Rp123000.00
Description:
The SIEMENS SITRANS LR560 is a high-performance radar level transmitter designed for continuous level measurement in solids and liquids. Utilizing Microwave Radar Technology, the SITRANS LR560 offers unparalleled accuracy and reliability for various industrial applications, such as bulk solids, slurry, and liquids. It is ideal for applications that require non-contact level measurement, even in harsh conditions.
With advanced signal processing and a robust design, the SITRANS LR560 can handle difficult environments, offering accurate level measurement without being affected by temperature, pressure, or dust. Its ability to measure from a distance makes it particularly useful in tanks, silos, and vessels with aggressive materials or extreme process conditions.
Key Features:
Non-contact Measurement: The radar technology ensures precise level measurement without physical contact with the process, reducing wear and tear.
High Performance: Offers accurate measurements even in the presence of foam, condensation, and vapors.
Broad Application Range: Suitable for both liquid and solid materials, including aggressive, corrosive, and hazardous substances.
Long Measurement Range: Capable of measuring distances from a few millimeters to over 70 meters (230 feet), depending on the specific application.
Easy Setup and Operation: Features a user-friendly interface, with various configuration options for quick installation and startup.
Robust Design: Built to withstand extreme process conditions, such as high pressures, temperatures, and vacuum environments.
Signal Processing: Advanced algorithms and signal processing capabilities for reliable measurement even in challenging conditions.
Multi-language Display: Supports various languages for easy operation in global environments.
Minimal Maintenance: Due to the absence of moving parts, the device requires minimal maintenance, ensuring reliability over time.
HART Communication: For seamless integration with control systems and easy field calibration.
Technical Specifications:
Model: SITRANS LR560
Measurement Principle: Microwave Radar
Frequency Range: 6 GHz
Measurement Range:
Up to 70 meters (230 feet) for solids
Up to 30 meters (100 feet) for liquids (depending on the material)
Accuracy: ± 3 mm (0.12 inches)
Output Signal:
4-20 mA (analog)
HART Protocol (digital communication for easy diagnostics and configuration)
Process Connection: Various options including flanged, threaded, and hygienic connections
Temperature Range: -40°C to +200°C (-40°F to +392°F), depending on the configuration
Pressure Range: Up to 40 bar (580 psi), depending on the model and application
Electrical Power Supply: 18-30 VDC (depending on configuration)
Enclosure Rating: IP66/IP67 (dust-tight and water-resistant)
Display: Local LCD with multi-language support
Process Wetted Material: Stainless Steel, PTFE, and other corrosion-resistant materials depending on model
Certificates:
ATEX, FM, CSA (for hazardous locations)
CE, UL approved
Communication: HART, Modbus, and Profibus (optional based on model)
Applications:
Bulk Solids: Used for level measurement in silos, hoppers, and bins for materials like sand, cement, coal, and other bulk solids.
Liquids: Ideal for continuous level measurement in storage tanks, reactors, and vessels containing liquids such as water, chemicals, oils, and acids.
Slurries and Viscous Liquids: Effective in measuring slurries, sludge, and high-viscosity materials.
Aggressive Environments: Suitable for use in industries that involve aggressive or hazardous materials, such as chemical, petrochemical, and food processing.
Water and Wastewater: Used in water treatment plants for measuring wastewater levels or in reservoirs and other water-related applications.
