Fisher Type 122A Three-Way Switching Valve
Rp123000.00
Product Description
The Fisher Type 122A is a high-capacity, cost-effective three-way pneumatic switching valve designed for on-off applications. This versatile valve is suitable for diverging or converging gaseous services, diverging liquid services with gas-loaded liquids, and converging liquid services.
Key Features
Convenient Installation: Simplifies setup and reduces installation time.
Easy Leak Detection: Facilitates quick identification of leaks, ensuring reliable operation.
Easy Maintenance: Designed for straightforward servicing to minimize downtime.
Specifications
Body Size and End Connection Style:
Connections A and C: 3/4" and 1" NPT
Connection B: 3/4" NPT
Maximum Inlet Pressure: 150 psig (10.3 bar)
Outlet Pressure Range: 3 to 150 psig (0.2 to 10.3 bar)
Temperature Range: -20°F to 150°F (-29°C to 66°C)
Approximate Weight: 5 pounds (2 kg)
Additional Information: For more technical details, contact your local sales office or refer to the technical documentation.
