Fisher 1080 Declutchable Manual Actuator
Rp123000.00
The Fisher 1080 manual actuator is a declutchable device designed for manual operation of control valves equipped with a 1035/El-O-Matic power actuator. It mounts directly onto the 1035 actuator and can be engaged to allow manual valve operation when the power actuator is either disengaged or not in use.
Specifications
Actuation: Rotary, Manual
Certifications: PED, CUTR, ATEX
Control Type: On/Off, Positioning
Power Source: Manual
Valve Compatibility: Ball Valve, Butterfly Valve, Eccentric Plug Valve, Triple Offset Valve
Additional Configurations: For more details about additional specifications or options, consult your local Emerson business partner or sales office.
Features
Direct Mounting: Simplifies installation by attaching directly to the actuator housing, eliminating the need for extra mounting components.
Engagement Mechanism: A lever-operated eccentric bearing on the input shaft allows worm gear engagement with the sector at any rotation point.
Size Compatibility: Each size of the 1080 actuator matches the capabilities of the corresponding 1035 actuator size, ensuring simplified sizing calculations when ordering both actuators together.
Safety Mechanism: The disengagement lever is held securely in engaged or disengaged positions by a spring-loaded pin that must be released before the lever can be moved, minimizing the risk of accidental operation.
Stop-Pins: Provides additional operational reliability and precision.
